Die neue MINOX pro

Stellar

The new MINOX tropic

  • made in Germany
  • Diamond Prism for homogeneous, glare-free light distribution
  • W RGB LED assembly
  • 5 LED colours
  • Professional full spectrum mid power LED
  • Controllable with LED controller
  • 3 separate channels individually controllable with lynk Controller





Aquariums perfectly staged

The new MINOX tropic is a premium LED light even for ambitious tropical aquariums and impresses with its elegant, ultra-flat design and amazing brightness. The new MINOX tropicis already equipped with a pre-configured WRGB light spectrum, optimizedfor fish and aquarium plants. Its special color composition of different colored LEDs addresses the entire color spectrum for aquarium plants and also highlights red, green as well as blue shades in the aquarium.


Unique light distribution

In addition to the extensive colour spectrum, the new MINOX tropic offers a unique light system. The integrated Diamond Prism optics have a diamond-shaped prism structure and thus guarantee perfect colour mixing of all colours as well as the highest possible light yield. This new light optic achieves an even and broadly diffused illumination with almost no loss of light. At the same time this optic avoids any glare when looking into the aquarium.

The new MINOX tropic is splash-proof and ensures constant brightness with intelligent power management and high-quality LEDs. The sophisticated thermal management ensures a long service life of the LED. With an enormously high light output of the white LED of more than 220 lumens per watt, the MINOX tropic is particularly energy-efficient and absolutely safe thanks to the 24-volt technology.

Stellar
Stellar

Design meets performance

  • Unique lighting system with Diamond Prism Optics for highest light yield and perfect colour mixing
  • Optimal illumination of the aquarium due to the almost loss-free Diamond Prism Optics
  • Durable quality: the splash-proof construction protects all electronics
  • Premium aluminium housing for optimal temperature dissipation in silver anodised surface and black or white glass element
  • Constant brightness thanks to state-of-the-art lighting technology and high-quality, efficient power supply unit
  • State-of-the-art coloured LED chips with high energy efficiency and white LEDs with more than 220 lumens/watt
  • Various mounting options as pendant luminaire or for mounting on the aquarium rim
  • Of course made in Germany and with up to four years warranty





Stellar

True to nature light effects

Optimal for the different light requirements of aquarium plants and fish.

Rich colours

The entire, biologically sensible spectrum for optimal, algae-free plant growth in freshwater aquariums is covered.

Pre-assembled light scenario ex works - can be individually readjusted and dimmed as desired with the lynk Aquarium Controller or the Light-controller.

Farben

Comfortable controllable

The MINOX LED aquarium lighting already has the optimal light spectrum for the respective application.

For individual adaptation, these can be connected to our newly developed lynk WIFI -Control Interfaces simply by "plug and play" and thus enable the realistic simulation of sunrises and sunsets as well as numerous weather simulations.

The three individual light groups can be controlled individually in terms of both colour selection and intensity. But also with the new LED controller, which has a large display, you can create your own daily plans for natural sunrises and sunsets.

Premiumklasse

Flexible mounting

The MINOX is basically designed as a light for open aquariums. You can easily mount the MINOX with the optionally available mounting arm. The mounting arm is adjustable in height.
With the "extension adapter", you can also optimally illuminate tanks that have a depth of more than 60 cm.
A mounting bracket in combination with a cable holder is also available as a further mounting accessory.


Mounting arm

The mounting arm makes it possible to attach your MINOX or TESZLA evo easily to the edge of the aquarium without any effort.
It is adjustable in height and thus the distance of the lamp to the water surface can be adjusted flexibly.

The total height adjustment is 15 cm.
The mounted lamp protrudes 37 cm forward. Thus, this mounting arm is optimal for aquariums with a width of at least Width of at least 50 cm.

The mounting arm is suitable from a glass thickness of 8 mm to 15 mm.



  • Weight: 0,5 KG
  • Total height:30 cm
  • Depth: 15 cm
  • Suitable for glass thickness: 8 - 15 mm
  • Adjustable in height: 15 cm
  • Optionally available extension / depth







Technical details MINOX tropic

LED power / energy consumption 45 Watt
Size 225 x 166 mm
LED Colors 5
Quantity LEDs
98
luminous flux 4450 Lumen
LED Typ Ceramic Midpower
Optic / Light distribution Prismatisch
Weight ca. 770 Gramm
Illuminated area 50 x 50 cm
Mains voltage 24 V / externes Netzteil



Lichttechnische Auswertung MINOX tropic

Parameter Kanal 1-3 Kanal 1 Kanal 2 Kanal 3
CCT 6700 K 6373 K 7047 K 7882 K
CIE 1931 x 0,3098 0,3150 0,2818 0,3155
CIE 1931 y 0,3250 0,3302 0,4299 0,2372
CRI (RA) 97 84 65 13
Re(R1~R15) 94 78 49 -17
GAI 100,9 90,2 51,9 153,2
Illuminance level (lx)
16400 lx
8861 lx 4904 lx 3226 lx
PPFD (μmol/ ㎡ s) 253.74 127,77 59,28 73,29
λp 452 nm 451 nm 521 nm 636 nm
λD 487 nm 490 nm 519 nm
0 nm
Ft Candela
1523.7 823,2 455,3 299,7
